Laser Alignment for Automotive

Laser alignment and measurement solutions for the automotive industry including bore and lathe alignment, positioning and more.




For over 25 years, Pinpoint Laser Systems has been helping automotive component manufacturers to increase their throughput, quality, and profitability by ensuring the validity of their equipment and processes utilizing our proprietary laser alignment systems. From powertrain components to acoustic liners, baffles and shields, Pinpoint will work with our customers’ design and engineering group to create the custom laser alignment and measuring systems for your specific needs.


Automotive Alignment Applications

  • Axle Turning – Lathe Alignment
  • Robotic Systems
  • Engine Timing Systems – Bore Alignment
  • Automated Welding Systems
  • Interior Acoustic Fiber – Forming Press Alignment
  • Crankshaft & Cam Alignment – Adjusting Extrusion Press Rams
  • Valve Train – Vertical Platen Press Leveling & Flatness
  • Engine & Gear Mounts – Position and Flatness Measurement
  • Fender Silencers – Forming and Cutting Press Alignment


Automotive Alignment Customers

  • Cummins
  • Mitsubishi/Quadrent
  • American Axle and Manufacturing
  • Emergency One
  • Pittsburgh Glass Works
  • Unique Fabricating
  • JKEKT Automotive
  • Stoughton Trailers




Typical estimated industry savings: $90,924 per year with a 4 month ROI. To calculate your own savings, please visit our ROI Calculator.

Find your solution here

Not sure which laser alignment product is right for your job? Get expert advice from our engineers, contact us today.
