Additional Info
Display Unit
Microgage PRO Smart Display
[simple_tooltip content=’
Smart Display delivers a bright, high-definition, color readout so the user can see & work with their measurement results. The digital reading of the laser’s position will read “0” for height & lateral readings if laser & receiver rest on the same plane & against a straight guide rail. If the receiver is moved, the measurement readings will change accordingly.’][/simple_tooltip]
Laser Transmitters
Microgage Laser Transmitter
[simple_tooltip content=’
The Microgage PRO transmitter forms a straight laser reference line for a machine or assembly and each receiver measures in two axial directions, horizontal and vertical (X & Y). The Microgage PRO measures within a precision of 0.0001 inch over distances of up to 180 feet.’][/simple_tooltip]
Microgage Cylindrical Laser
[simple_tooltip content=’
Several cylindrical lasers are available for use with the Microgage laser alignment kit and are ideal for bore and spindle alignment or in place of a traditional scope or autocollimator.’][/simple_tooltip]
Microgage Receivers
Microgage 2 Axis PRO Receiver
[simple_tooltip content=’
A variety of Microgage receivers is available for use with the Microgage Systems. Options include 1 inch, 0.75 inches, 0.5 inches, 3.0 inch, and a variety of cylindrical receivers and other receiver designs. Pinpoint will also modify housings and receivers to fit your particular needs.’][/simple_tooltip]
Microgage 2 Axis Disk Receiver
[simple_tooltip content=’
The Microgage Disc Receiver is compact enough fit into small places for bore alignment, checking extruder barrels, shaft bearings and much more. A narrow laser beam provides a measuring reference line and this receiver will determine the X – Y position of a machine or sub-assembly relative to the laser reference beam.’][/simple_tooltip]
Microgage 4 Axis Receiver
[simple_tooltip content=’
This receiver provides a precise measure of its linear position and angular orientation to the centerline of the laser reference beam. Horizontal and vertical position are available to a precision of 0.0002 inch (5 micron) and angular pitch and yaw readings are precise to 0.005 degree or 15 arc-seconds.’][/simple_tooltip]
Microgage 2 Axis Transparent Receiver
[simple_tooltip content=’
This receiver allows the laser reference beam to pass cleanly through to other receivers while making a precise pair of linear measurements. The position of this receiver measures in real time to the centerline of the laser beam for precise measurements of machine tool motion and other industrial applications.’][/simple_tooltip]
Microgage 2 Axis Bore Receiver
[simple_tooltip content=’
The Microgage Bore Receiver is an innovative solution for precisely measuring the straightness of a tube or bore. The receiver comes with sets of interchangeable collars that are designed to precisely fit the bore inside diameter.’][/simple_tooltip]
Microgage 2 Axis Wireless Receiver
[simple_tooltip content=’
The Microgage 2-Axis Receiver provides precise X-Y measurements to a precision of 0.0001 inch (2.5 µ). The durable machined enclosure has mounting points for fixtures and mounts and quality optics and components ensure years of reliable use in tough industrial settings.’][/simple_tooltip]
Microgage 4 Axis Wireless Receiver
[simple_tooltip content=’
This wireless 4D receiver measures X-Y and their angular components Pitch and Yaw without the use of connecting cables. This wireless capability allows for measurements deep inside machinery and provides a measuring resolution of 0.0002 inch (5 µ) in X and Y and 0.005 degree or 15 arc-seconds in the angular, pitch and yaw, axes.’][/simple_tooltip]
Microgage Transparent Wireless Receiver
[simple_tooltip content=’
The wireless transparent receiver operates free of wires and connecting cables and provides precise X-Y measurement of the receiver relative to the centerline of the laser reference beam. The laser reference beam passes cleanly through the receiver’s housing, for the measurement, and extends on for use with other receivers.’][/simple_tooltip]
Microgage Wireless Junction
[simple_tooltip content=’
This junction box is like a wireless extension cord for your Microgage receivers. One or two receivers plug directly into this junction box and a wireless signal transmits their measurement data to the Microgage PRO display. An ideal solution for adapting a wired receiver to wireless use and longer-range operation.’][/simple_tooltip]
Mounting
4 Axis Precision Mount
[simple_tooltip content=’
This adjustment mount supports the Laser Microgage or other third party laser transmitters and allows precise beam control in the two linear axes: left-right and up-down. Two precision angular motions pitch and swing are also provided.’][/simple_tooltip]
2 Axis Precision Mount
[simple_tooltip content=’
This mount provides accurate, linear control in two axes for Microgage receivers, the 90-Line and other accessories. Two precise adjustment knobs move the mounting surface in the X and Y-axes.
‘][/simple_tooltip]
Leveler Rotational Mount
[simple_tooltip content=’
This is a precision laser alignment-leveling mount to support the laser for measuring and setting flat reference planes. The laser and mount align by several fine adjustment knobs and can rotate to any position for defining a flat plane.
‘][/simple_tooltip]
Receiver Bore Mount
[simple_tooltip content=’
The Receiver Bore Mount is available for high precision bore alignment applications on journals, extruder tubes, precision bores, and related alignments. The mount supports the Microgage Receiver and fits into the bore with precision registration based upon 2 defined tooling ball reference points.
‘][/simple_tooltip]
Precision Tripod Mount
[simple_tooltip content=’
This sturdy tripod supports the laser with the Leveler Rotational Mount or 4-Axis Precision Mount and is ideal for mounting reference receivers, 90-Lines and other devices for long machinery runs. The solid design has lift control and expands from 28″ to 55″.
‘][/simple_tooltip]
Adjustable Receiver Mount
[simple_tooltip content=’
The Adjustable Mount supports the Laser Microgage Receiver on machinery, assemblies, and moving equipment. This mount is ideal for many machine tool and assembly alignment and measuring tasks.
‘][/simple_tooltip]
Magnetic On/Off Mount
[simple_tooltip content=’
The Magnetic Mount Assembly is a standard component in the Microgage 2000 kit and ideally suited for supporting the Microgage receiver, 90-Line, and other accessories. The mount also includes a fixed base for added versatility.
‘][/simple_tooltip]
Optical Attachments
90-Line E – Right Angle
[simple_tooltip content=’
The 90-Line places into the laser path and forms a precise right angle laser alignment beam that is ideal for squaring machinery, checking parallelism and other tasks. The 90-Line is ideal for working in a two-dimensional area.
‘][/simple_tooltip]
90-Line D – Right Angle
[simple_tooltip content=’
The 90-Line-D builds upon the Enhanced 90-Line by including a built-in detector that monitor the incoming laser beam and actively corrects for any misalignments or small errors.
‘][/simple_tooltip]
Software Applications
Microgage DCU & Capture Software
Capture Data Applications
Microgage PRO Display Routines
Custom Data Applications
